Automatic Powder Coating/Spraying Gun System
It is very easy to operate for a beginners, powerful for advanced users; High productivity, little labor cost. Application: all kinds of metal workpieces, whether flat parts or with awkward corners, provides perfect powder
Automatic Powder Coating Spray Gun
***Product and Feature
JOBON brand S20 Automatic Powder Coating Spray Gun
Control way: touch screen
Patent: 5patents included
Certification: CE
Factory: ISO9001
Year in the market: 2021
Origin: China
Recommended Setting for Plate/Panel parts:
kV: 80
uA: 30
Recommended Setting for Grooved parts:
kV: 50
uA: 70
Recommended Setting for Repair operation:
kV: 25
uA: 50
When you put the setting to do Repair, the setting is fixed and locked by system. You can just follow the system setting to do the Repair job.
S20 Automatic Powder Coating Spray Gun Parameters:
Power | AC100~240v/50~60Hz(self-adaptive) |
Max Power | 50W |
Safety Level | IP54 |
Ambient Temperature | 0~40℃ (+32~+104℉) |
Input Pressure | 0.55Mpa (5.5bar, 80PSI) |
Electrostatic Polarity | Negative |
Max Output Voltage | 150kV |
Max Output Current | 120uA |
Standard Weight of Pistol | 580g |
Standard Pistol Length | 33cm (trigger to tip) |
Pistol feeding hose length | 3.5m |
Max Powder Output | 650g/min |
Volume of Powder Bucket | 52L |
S20 automated powder coating gun has two ways of master control function. Detailed as below chart:
***Application
S20 automatic powder coating spray gun has good coating performance for all types of metal parts, deep groove parts and crossing point parts etc.
***Working Video
Youtube:
***Warranty/After Sales Service
(1) Two-year warranty for cascade and circuit board
(2) Maintenance parts available all the time
(3) 24hours on line sales service available
***About JOBON company
(1) ISO9001
(2) High-Tech factory
(3) Start from 1999 to manufacture and supply powder coating machinery
Hot Tags: automatic powder coating/spraying gun system, suppliers, manufacturers, price, for sale
